-30 ℃ Meling undercounter type biomedical freezer DW-XL90

Built-in possibility
Slim and golden dimension
Environment-friendly HC refrigerator
10 audible and visual alarms for storage security
Fast cooling

Request A Quote Downloads

Overview

Meling undercounter type biomedical freezer DW-XL90 designed to meet a wide range of sample storage needs, with hydrocarbon refrigerant and fast cooling capabilities. Built-in design with front ventilation make the refrigeration perfomance still be guaranteed even if it works in narrow sapce. It offers an unparalleled ergonomic design and ideal for the storage of a wide variety of samples including enzymes, biologics,plasma and medicines.

Built-in possibility

Front-breathing ventilation design makes no worry about limited space around or aside the freezer.

Hydrocarbon refrigerant

R290 refrigerant complies with SNAP and F Gas mandates.Energy consumption meets Energy Star standard(Lab grade freezer).

Slim and golden dimension

Size of 600*620*810mm is suitable for using in most laboratory and pharmacy under counter,height (less than 32'') complying with ADA guidelines.

Alarms system

10 audible and visual alarms for storage security. Self charging battery module to guarantee that the elec-tronic control system is still in full operation 48 hours after power failure.

Features

Small volume undercounter ultra low freezer occupies small space
The system has the function of digital temperature display and temperature inside the cabinet can be set with in range from -15℃ to -30℃
The high-precision microcomputer temperature control system and platinum resistor temperature sensors ensure more precise temperature control
Standard adjustable wire shelves and basket provides storage flexibity.
Temp. Max./Min.Display accuracy of 0.1 ℃
Front ventilation design allows freezer working in limited space with outstanding performance

Scope of Application

Suitable for use in scientific research, cryogenic test on special materials,low temperature resistance test on biological materials, vaccines, biological products and military products, etc. Suitable for use in research institutions, the electronic industry, the chemical industry, hospitals, the health & disease prevention system, laboratories in colleges & universities, etc.

Product Brochure Download

Please click the OneDrive link to download the product brochure:Product Brochure- Meling Biomedical

Specifications

-30℃ Biomedical Freezer
Model	DW-XL90
Power supply	110/60
Capacity(L）	90L/3.18Cu.Ft
Internal size(WDH)mm)/inch	440465480mm/17.3218.318.9 inch
External size(WDH)mm/inch	600622812mm/23.6224.531.9 inch
Package size(WDH)mm/inch	662682892mm/26.0626.8535.12 inch
NW(Kgs)	52
Performance
Temperature range	-15～-30℃/5°F~-22°F
Ambient temperature	16-32℃/60.8°F~89.6°F
Controller	Microprocessor
Display	Digital display
Noise	50dB(A)
Refrigeration
Compressor	1pc
Cooling method	Direct cooling
Defrost mode	Manual
Refrigerant	R290
Insulation thickness(mm)	80
Construction
External material	PCM
Inner material	Spraying Aluminum liner
Shelves	2+1 (basket)
Access port	1pc. Ø 36 mm
Casters	2(2 leveling feet)
Data logging/Interval/Max data capacity	USB (Built-in data logger)
Interface	Remote alarm contact; RS485
Alarm
Temperature	High/Low temperature, High ambient temperature
Electrical	Power failure,Low battery
System	Sensor failure,Door ajar,Built-in USB datalogger failure, Communication failure

Download

DW-XL90.pdf
