New Arrival -86°C Dual core System Ultra Low Freezer Freezer 428 liters for Laboratory DW-HL428T New Arrival -86°C Dual core System Ultra Low Freezer Freezer 428 liters for Laboratory DW-HL428T New Arrival -86°C Dual core System Ultra Low Freezer Freezer 428 liters for Laboratory DW-HL428T

New Arrival -86°C Dual core System Ultra Low Freezer Freezer 428 liters for Laboratory DW-HL428T

•Two high-efficiency refrigeration systems

•10.1''LCD touch screen

•VIP insulation foaming

•10 kinds of alarm functions

Request A Quote
Overview

 -86℃ Ultra Low Temperature Freezer DW-HL428T built up by two independent refrigeration systems, and the Dual Cooling Systems offers the highest level of protection, only one system work can maintain the freezer around the -80℃. Valuable and irreplaceable samples can always be securely with the highest confidence even if the compressor fails.



Two High-efficiency Refrigeration Systems

Two high-efficiency refrigeration sytems work independently, each independent refrigeration system ensures the freezer temperature remains at  -80℃. Valuable and irreplaceable samples can always be securely stored with the highest confidence.



Environment Friendly

Employs natural hydrocarbon refrigerants in full compliance with U.S. SNAP and EU (EU_517/2014) environmental regulations. All manufacturing foaming agents are strictly controlled to meet eco-safety standards.



User Interface and Functionality



-10-inch high-resolution LCD touchscreen with glove-compatible operation



-USB port for data transfer, event logs, and system diagnostics



-Switchable ℃/℉ display modes for user convenience



-Setup wizard and on-screen temperature mapping for simplified configuration



-loT Function (WIFI/5V power supply interface/Network interface)



-RS485 interface compliance to MODBUS protocol is able to transfer data with




Energy Efficiency

Equipped with inverter compressors that dynamically adjust operation based on internal conditions. During idle phases, the system runs at minimal speeds to reduce consumption and automatically accelerates following door openings to quickly restore target temperatures.
Features



  • Two high-effiency refrigerant systems work indepently, each independent refrigeration system ensures the freezer temperature remains at  -80℃. Valuable and irreplaceable samples can always be securely stored with the highest confidence.

  • Temperature uniformity 2.7 ℃

  • 180 mins pull down to -80℃

  • 6.5 Kwh daily consumption

  • High-definition and easy-handling control panel to set the temperature range from -40°C to -86°C with digital temperature display precision in 0.1°C

  • Lockable door, keyboard lock and password access prevents any unauthorized access and operation

  • China's leading manufacturer of ultra-low temperature freezer

Scope of Application  Scope of Application

Ultra low deep freezer DW-HL428T can be used as laboratory freezer, ultra low medical freezer and deep freezer，suitable for use in hospitals, health and disease prevention systems, research institutions, colleges & universities, the electronic industry, biological engineering, laboratories in colleges & universities, military enterprises, deep-sea fishing companies, etc.

Scope of Application  Product Brochure Download

Please click the OneDrive link to download the product brochure: Product Brochure - Meling Biomedical

Specifications
-86℃ Ultra-low Temperature Freezer
Model    DW-HL428T
  Capacity(L) 428
Internal size(W*D*H)cm/inch 460*712*1290/ 18.11*28.03*50.79
External size(W*D*H)cm/inch

770*1031*1994/ 30.31*40.59*78.5
Package size(W*D*H)mm/Inch   823*1157*2160/ 32.4*45.55*85.04
NW/GW(Kgs) 263/580
Performance
Temperature range -40～-86℃
Ambient temperature 16-32℃
Cooling performance -86℃
Climate class N
Controller Microprocessor
Display 10.1‘’HD Intelligent touch screen
Refrigeration
Compressor 2pcs （Inverter Technology）
Cooling method Direct cooling
Defrost mode Manual
Refrigerant HC
Insulation thickness(mm) D:104，L/R:110,B:110
Construction
External material

Cold rolled steel
Inner material Galvanized sheet (Optional stainless steel)
Shelves 3(stainless steel)
Access port 2pc. Ø 25 mm
Casters 4+(2 leveling feet)
Data Logging/Interval/Memory Capacity USB/Record every 5 minutes / 10 years
Backup battery Yes
Alarms
Temperature High/Low temperature,High ambient temperature,Condenser high temperature alarm
Electrical Power failure , Low battery,Battery power detection failure
System Data communication failure, door ajar, ambient temperature sensor failure,condenser sensor failure, temperature sensor failure
Electrical
  Power (W) 220-240/50
  Rated Current(A) 9.5
